63V 100µF ±20% 0.35ohm 400mA 2K Hours UE Series

SMD Aluminum Electrolytic Capacitors, Low ESR/Impedance type, UE series, 2 pads Capacitance: 100μF, Tolerance ±20%, Voltage 63V, Case size: : ØD10.0*L10.2mm, Impedance 0.35Ω, 2000 Hours, RC: 400 mA (at 105 °C,100KHz), Operating Temp. Range -55°C ~+105°C

Key Features:
  • Series: UE
  • Capacitance: 100µF
  • Capacitance Tolerance: ±20%
  • Rated Voltage: 63V
  • Ripple Current @+105°C, 100KHz: 400mA Max.
  • Lifetime @105°C: 2000 Hours
  • Leakage Current: 63 (μA)max
  • Impedance @20℃,100KHz: 0.35ohm Max.
See Full Specification

$0.54500

Out of stock
SKU UE107M063HGKTA
Original MPNCAE107M1JHUEGJ2TR
Datasheet Data Sheet

Description

SMD Aluminum Electrolytic Capacitors, Low ESR/Impedance type, UE series, 2 pads Capacitance: 100μF, Tolerance ±20%, Voltage 63V, Case size: : ØD10.0*L10.2mm, Impedance 0.35Ω, 2000 Hours, RC: 400 mA (at 105 °C,100KHz), Operating Temp. Range -55°C ~+105°C

  • Polar Aluminum Electrolytic Capacitor (Foil Type)
  • High stability and reliability
  • Lifetime 2000 Hours @ 105°C
  • Designed Capacitor’s Quality Meets IEC60384.
  • Applicable To Automatic Mounting Machine
  • Cross Competitors Parts and more.
  • RoHS Complaint And Halogen Free

APPLICATION

  • High-density Patch Assembly General Electronic Circuit Etc.

Specification

Series

UE
Capacitance

100µF
Capacitance Tolerance

±20%
Rated Voltage

63V
Case Size

ØD10.0*L10.2mm
Ripple Current @+105°C, 100KHz

400mA Max.
Lifetime @105°C

2000 Hours
Operating Temp. Range

-55°C ~+105°C
Dissipation Factor @+20°C, 120Hz Tanδ Max.

0.10 Tanδ Max.
Leakage Current

63 (μA)max
Impedance @20℃,100KHz

0.35ohm Max.
Mounting Type

Surface Mount, 2 pads
RoHS Status

RoHS III Compliant & Halogen Free
Moisture Sensitivity Level (MSL)

1 (Unlimited)
REACH Status

REACH Unaffected
HTSUS

8532.22.0020
ECCN

EAR99
Standard Package (MPQ)

500pcs/Reel, Quantity entered must be multiple of 500
NCNR

Non-Cancelable/Non-Returnable
