63V 10µF ±20% 120 mohm Max. 700mA 4K hours AEC-Q200 BW Series

Conductive Polymer Hybrid Aluminum Electrolytic Capacitors BW series, Capacitance: 10µF, Tolerance ±20%, Voltage 63V, 2 pads, Case size: ØD6.3*L5.8mm, Ripple Current 700mA Max.@+125℃, 100KHz, Lifetime 4000Hours @125°C, ESR @125°C,100KHz: 120 mohm Max., Operating Temp. Range -55°C ~+125°C, Leakage Current: 6.3μA @at 20℃ after 2 minutes

Key Features:
  • Series: BW
  • Capacitance: 10µF
  • Capacitance Tolerance: ±20%
  • Rated Voltage: 63V
  • Impedance @20℃,100KHz: 120mohm Max.
  • Lifetime @125°C: 4000 Hours
  • Rating: AEC-Q200
See Full Specification

$1.68550

Out of stock
SKU BW106M063HEHTA
Original MPNCXE106M1JHBWEE8TRC
Datasheet Data Sheet

Description

Conductive Polymer Hybrid Aluminum Electrolytic Capacitors BW series, Capacitance: 10µF, Tolerance ±20%, Voltage 63V, 2 pads, Case size: ØD6.3*L5.8mm, Ripple Current 700mA Max.@+125℃, 100KHz, Lifetime 4000Hours @125°C, ESR @125°C,100KHz: 120 mohm Max., Operating Temp. Range -55°C ~+125°C, Leakage Current: 6.3μA @at 20℃ after 2 minutes

• Conductive Polymer Hybrid Aluminum Electrolytic Capacitors
• High Stability And Reliability, Low ESR, High Ripple Current
• Long Life 4000 Hours @ 125°C
• Quality and standard Meets IEC 60384-4 and AEC-Q200-REV D
• Applicable To Automatic Mounting Machine
• Cross Competitors PARTS GYA, HZC, ZC And HXC Series And More.
• RoHS III Complaint And Halogen Free

APPLICATION

• For Applications Automotive and more
