SMD Aluminum Electrolytic Capacitors, UH series, 2 pads Capacitance: 47µF, Tolerance ±20%, Voltage 35V, Case size: Ø6.30mm*L7.70mm, Impedance 0.45Ω, 300mA, 2000 Hours, Operating Temp. Range -40°C ~+125°C
SMD Aluminum Electrolytic Capacitors, UH series, 2 pads Capacitance: 47µF, Tolerance ±20%, Voltage 35V, Case size: Ø6.30mm*L7.70mm, Impedance 0.45Ω, 300mA, 2000 Hours, Operating Temp. Range -40°C ~+125°C
• SMD Aluminum Electrolytic Capacitors
• Designed for SMD on PCB
• Applicable to automatic mounting machine
• RoHS Complaint and Halogen Free
APPLICATION
• Electronic Equipment
| Series | UH |
|---|---|
| Capacitance | 47µF |
| Capacitance Tolerance | ±20% |
| Rated Voltage | 35V |
| Case Size | Ø6.30mm*L7.70mm |
| Ripple Current @+105°C, 100KHz | 300mA Max. |
| Lifetime @105°C | 2000 Hours |
| Operating Temp. Range | -40°C ~+125°C |
| Dissipation Factor @+105°C, 100KHz | 0.14 Tanδ Max. |
| Impedance @20℃,100KHz | 0.45ohm Max. |
| Mounting Type | Surface Mount, 2 pads |
| RoHS Status | RoHS III Compliant & Halogen Free |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| REACH Status | REACH Unaffected |
| HTSUS | 8532.22.0020 |
| ECCN | EAR99 |
| Standard Package (MPQ) | 1000pcs/Reel, Quantity entered must be multiple of 1000 |
| NCNR | Non-Cancelable/Non-Returnable |
