35V 470µF ±20% 380mA 2K Hours UT Series

SMD Aluminum Electrolytic Capacitors, Wide Temperature Standard Type, UT series, 2 pads Capacitance: 470µF, Tolerance ±20%, Voltage 35V, Case size: ØD10.0*L10.2mm, Ripple Current 380mA Max.@+105℃, 120Hz, Lifetime 2000Hours @105°C, Operating Temp. Range: -55°C ~+105°C

Key Features:
  • Series: UT
  • Capacitance: 470µF
  • Capacitance Tolerance: ±20%
  • Rated Voltage: 35V
  • Ripple Current @+105°C, 120Hz: 380mA Max.
  • Lifetime @105°C: 2000 Hours
  • Leakage Current @20 °C: 164.5µA Max.

$0.78850

SKU UT477M035HGKTA
Original MPNCAE477M1VHUTGJ2TR
Datasheet Data Sheet
Add to wishlist

Description

SMD Aluminum Electrolytic Capacitors, Wide Temperature Standard Type, UT series, 2 pads Capacitance: 470µF, Tolerance ±20%, Voltage 35V, Case size: ØD10.0*L10.2mm, Ripple Current 380mA Max.@+105℃, 120Hz, Lifetime 2000Hours @105°C, Operating Temp. Range: -55°C ~+105°C

• Polar Aluminum Electrolytic Capacitor (Foil Type)
• High stability and reliability
• Lifetime 2000 Hours @ 105°C
• Designed Capacitor’s Quality Meets IEC60384.
• Applicable To Automatic Mounting Machine
• Cross Competitors Parts FN, FKS, MVE UUT SKV, SGV Series and more.
• RoHS Complaint And Halogen Free

APPLICATION

• High-density Patch Assembly General Electronic Circuit Etc.
