25V 470µF ±20% 0.23ohm 360mA 2K Hours UE Series

SMD Aluminum Electrolytic Capacitors, Low ESR/Impedance type, UE series, 2 pads Capacitance: 470µF, Tolerance ±20%, Voltage 25V, Case size: : ØD10.0*L10.2mm, Impedance 0.23Ω, 2000 Hours, RC: 360 mA (at 105 ℃,100KHz), Operating Temp. Range -55°C ~+105°C

Key Features:
  • Series: UE
  • Capacitance: 470µF
  • Capacitance Tolerance: ±20%
  • Rated Voltage: 25V
  • Ripple Current @+105°C, 100KHz: 360mA Max.
  • Lifetime @105°C: 2000 Hours
  • Leakage Current: 117.5(μA)max
  • Impedance @20℃,100KHz: 0.23ohm Max.
See Full Specification

$0.55500

Out of stock
SKU UE477M025HGKTA
Original MPNCAE477M1EHUEGJ2TR
Datasheet Data Sheet

Description

SMD Aluminum Electrolytic Capacitors, Low ESR/Impedance type, UE series, 2 pads Capacitance: 470µF, Tolerance ±20%, Voltage 25V, Case size: : ØD10.0*L10.2mm, Impedance 0.23Ω, 2000 Hours, RC: 360 mA (at 105 ℃,100KHz), Operating Temp. Range -55°C ~+105°C

• SMD Aluminum Electrolytic Capacitors
• Wide Temperature
• Low Impedance & ESR
• Designed For SMD On PCB
• Applicable To Automatic Mounting Machine
• RoHS Complaint And Halogen Free

APPLICATION

• High-density Patch Assembly Electronic Circuit, Power Supply, Lighting, Etc

Specification

Series

UE
Capacitance

470µF
Capacitance Tolerance

±20%
Rated Voltage

25V
Case Size

ØD10.0*L10.2mm
Ripple Current @+105°C, 100KHz

360mA Max.
Lifetime @105°C

2000 Hours
Operating Temp. Range

-55°C ~+105°C
Dissipation Factor @+20°C, 120Hz Tanδ Max.

0.14 Tanδ Max.
Leakage Current

117.5(μA)max
Impedance @20℃,100KHz

0.23ohm Max.
Mounting Type

Surface Mount, 2 pads
RoHS Status

RoHS III Compliant & Halogen Free
Moisture Sensitivity Level (MSL)

1 (Unlimited)
REACH Status

REACH Unaffected
HTSUS

8532.22.0020
ECCN

EAR99
Standard Package (MPQ)

500pcs/Reel, Quantity entered must be multiple of 500
NCNR

Non-Cancelable/Non-Returnable
