25V 22µF ±20% 1.9ohm 80mA 2K Hours UE Series

SMD Aluminum Electrolytic Capacitors, Low ESR/Impedance type, UE series, 2 pads Capacitance: 22µF, Tolerance ±20%, Voltage 25V, Case size: Ø5.00*L5.40mm, Impedance 1.9Ω, 2000 Hours
Ripple Current: 80mA @ +105℃, 100KHz, Operating Temp. Range -55°C ~+105°C

Key Features:
  • Series: UE
  • Capacitance: 22µF
  • Capacitance Tolerance: ±20%
  • Rated Voltage: 25V
  • Ripple Current @+105°C, 100KHz: 80mA Max.
  • Lifetime @105°C: 2000 Hours
  • Leakage Current: 5.5 (μA)max
  • Impedance @20℃,100KHz: 1.9ohm Max.

$0.15500

Out of stock
SKU UE226M025HDHTA
Original MPNCAE226M1EHUEDE4TRC
Datasheet Data Sheet

Description

SMD Aluminum Electrolytic Capacitors, Low ESR/Impedance type, UE series, 2 pads Capacitance: 22µF, Tolerance ±20%, Voltage 25V, Case size: Ø5.00*L5.40mm, Impedance 1.9Ω, 2000 Hours
Ripple Current: 80mA @ +105℃, 100KHz, Operating Temp. Range -55°C ~+105°C

• Polar Aluminum Electrolytic Capacitor (Foil Type)
• High stability and reliability
• Lifetime 2000 Hours @ 105°C
• Designed Capacitor’s Quality Meets IEC60384.
• Applicable To Automatic Mounting Machine
• Cross Competitors Parts and more.
• RoHS Complaint And Halogen Free

APPLICATION

  • High-density Patch Assembly Electronic Circuit, Power Supply, Lighting, Etc.
