Description
SMD Aluminum Electrolytic Capacitors, ZS series, 2 pads, Capacitance: 100µF, Tolerance ±20%, Voltage 25V, Case size: ØD6.3*L7.7mm, Ripple Current 600 mA Max. @+105℃, 100KHz, Lifetime 2000Hours @105°C, ESR @20°C,100KHz: 0.16 ohm Max., Operating Temp. Range -55°C ~+105°C. Surge Voltage: 28.8V, Leakage Current: 25μA @at 20℃ after 2 minutes
• Polar Aluminum Electrolytic Capacitor (Foil Type)
• High stability and reliability
• Lifetime 2000 Hours @ 105°C
• Designed Capacitor’s Quality Meets IEC60384.
• Applicable To Automatic Mounting Machine
• Cross Competitors Parts
• RoHS Complaint And Halogen Free
APPLICATION
• High-density Patch Assembly General Electronic Circuit Etc.
