16V 47µF ±20% 1.1ohm 115mA 2K Hours UE Series

SMD Aluminum Electrolytic Capacitors, Low ESR/Impedance type UE series, 2 pads Capacitance: 47µF, Tolerance ±20%, Voltage 16V, Case size: ØD6.3*L5.40mm, Impedance 1.1Ω, 2000 Hours, RC: 115 mA (at 105 ℃,100KHz), Operating Temp. Range -55°C ~+105°C

Key Features:
  • Series: UE
  • Capacitance: 47µF
  • Capacitance Tolerance: ±20%
  • Rated Voltage: 16V
  • Ripple Current @+105°C, 100KHz: 115mA Max.
  • Lifetime @105°C: 2000 Hours
  • Leakage Current: 7.5(μA)max
  • Impedance @20℃,100KHz: 1.1ohm Max.

$0.18500

Out of stock
SKU UE476M016HEHTA
Original MPNCAE476M1CHUEEE4TRC
Datasheet Data Sheet

Description

SMD Aluminum Electrolytic Capacitors, Low ESR/Impedance type UE series, 2 pads Capacitance: 47µF, Tolerance ±20%, Voltage 16V, Case size: ØD6.3*L5.40mm, Impedance 1.1Ω, 2000 Hours, RC: 115 mA (at 105 ℃,100KHz), Operating Temp. Range -55°C ~+105°C

• SMD Aluminum Electrolytic Capacitors
• Wide Temperature
• Low Impedance & ESR
• Designed For SMD On PCB
• Applicable To Automatic Mounting Machine
• RoHS Complaint And Halogen Free

APPLICATION

• High-density Patch Assembly Electronic Circuit, Power Supply, Lighting, Etc.
