16V 220µF ±20% 0.85ohm 150mA 2K Hours UE Series

SMD Aluminum Electrolytic Capacitors, Low ESR/Impedance type, UE series, 2 pads Capacitance: 220µF, Tolerance ±20%, Voltage 16V, Case size: ØD6.3*L7.70mm, Impedance 0.85Ω, Ripple Current: 150mA Max. @+105℃, 100KHz, Lifetime 2000Hours, Operating Temp. Range -55°C ~+105°C

Key Features:
  • Series: UE
  • Capacitance: 220µF
  • Capacitance Tolerance: ±20%
  • Rated Voltage: 16V
  • Ripple Current @+105°C, 100KHz: 150mA Max.
  • Lifetime @105°C: 2000 Hours
  • Leakage Current: 35.2 (μA)max
  • Impedance @20℃,100KHz: 0.85ohm Max.

$0.25500

Out of stock
SKU UE227M016HEJTA
Original MPNCAE227M1CHUEEG7TRC
Datasheet Data Sheet

Description

SMD Aluminum Electrolytic Capacitors, Low ESR/Impedance type, UE series, 2 pads Capacitance: 220µF, Tolerance ±20%, Voltage 16V, Case size: ØD6.3*L7.70mm, Impedance 0.85Ω, Ripple Current: 150mA Max. @+105℃, 100KHz, Lifetime 2000Hours, Operating Temp. Range -55°C ~+105°C

• SMD Aluminum Electrolytic Capacitors
• Wide Temperature
• Low Impedance & ESR
• Designed For SMD On PCB
• Applicable To Automatic Mounting Machine
• RoHS Complaint And Halogen Free

APPLICATION

  • High-density Patch Assembly Electronic Circuit, Power Supply, Lighting, Etc.
