16V 150µF ±20% 0.85ohm 150mA 2K Hours UE Series

SMD Aluminum Electrolytic Capacitors, Low ESR/Impedance type, UE series, 2 pads Capacitance: 150µF, Tolerance ±20%, Voltage 16V, Case size: ØD6.3*L7.70mm, Impedance 0.85Ω, 2000 Hours RC: 150 mA (at 105 ℃,100KHz), Operating Temp. Range -55°C ~+105°C

Key Features:
  • Series: UE
  • Capacitance: 150µF
  • Capacitance Tolerance: ±20%
  • Rated Voltage: 16V
  • Ripple Current @+105°C, 100KHz: 150mA Max.
  • Leakage Current: 24(μA)max
  • Lifetime @105°C: 2000 Hours
  • Impedance @20℃,100KHz: 0.85ohm Max.

$0.15800

Out of stock
SKU UE157M016HEJTA
Original MPNCAE157M1CHUEEG7TRC
Datasheet Data Sheet

Description

SMD Aluminum Electrolytic Capacitors, Low ESR/Impedance type, UE series, 2 pads Capacitance: 150µF, Tolerance ±20%, Voltage 16V, Case size: ØD6.3*L7.70mm, Impedance 0.85Ω, 2000 Hours RC: 150 mA (at 105 ℃,100KHz), Operating Temp. Range -55°C ~+105°C

  • SMD Aluminum Electrolytic Capacitors
  • Wide Temperature
  • Low Impedance & ESR
  • Designed For SMD On PCB
  • Applicable To Automatic Mounting Machine
  • RoHS Complaint And Halogen Free

APPLICATION

  • High-density Patch Assembly Electronic Circuit, Power Supply, Lighting, Etc.

Specification

Series

UE

Capacitance

150µF

Capacitance Tolerance

±20%

Rated Voltage

16V

Case Size

Ø6.30*L7.70mm

Ripple Current @+105°C, 100KHz

150mA Max.

Leakage Current

24(μA)max

Lifetime @105°C

2000 Hours

Operating Temp. Range

-55°C ~+105°C

Dissipation Factor @+20°C, 120Hz Tanδ Max.

0.16 Tanδ Max.

Impedance @20℃,100KHz

0.85ohm Max.

Mounting Type

Surface Mount, 2 pads

RoHS Status

RoHS III Compliant & Halogen Free

Moisture Sensitivity Level (MSL)

1 (Unlimited)

REACH Status

REACH Unaffected

HTSUS

8532.22.0020

ECCN

EAR99

Standard Package (MPQ)

1000pcs/Reel, Quantity entered must be multiple of 1000

NCNR

Non-Cancelable/Non-Returnable
