Name: 16V 100µF ±20% 1.1ohm 115mA 2K Hours UE Series
SKU: UE107M016HEHTA
Price: 0.16 USD
Availability: InStock

Welcome to Aillen Capacitors !

Hello, Log In My Account

0 Shopping Cart $0.00000

SMD Aluminum Electrolytic Capacitors, Low ESR type, UE series, 2 pads Capacitance: 100µF, Tolerance ±20%, Voltage 16V, Case size: Ø6.30*L5.40mm, Impedance 1.1Ω, 2000 Hours, Ripple Current: 115mA @ +105℃,100KHz, Operating Temp. Range -55°C ~+105°C

Key Features:

Series: UE
Capacitance: 100µF
Capacitance Tolerance: ±20%
Rated Voltage: 16V
Ripple Current @+105°C, 100KHz: 115mA Max.
Lifetime @105°C: 2000 Hours
Leakage Current: 16 (μA)max
Impedance @20℃,100KHz: 1.1ohm Max.

See Full Specification

$0.15500

SKU	UE107M016HEHTA

Original MPN	CAE107M1CHUEEE4TRC
Datasheet	Data Sheet

Description
Specification

Description

• Polar Aluminum Electrolytic Capacitor (Foil Type)
• High stability and reliability
• Lifetime 2000 Hours @ 105°C
• Designed Capacitor’s Quality Meets IEC60384.
• Applicable To Automatic Mounting Machine
• Cross Competitors Parts and more.
• RoHS Complaint And Halogen Free

APPLICATION

• High-density Patch Assembly Electronic Circuit, Power Supply, Lighting, Etc.

Specification

Series	UE
Capacitance	100µF
Capacitance Tolerance	±20%
Rated Voltage	16V
Case Size	Ø6.30*L5.40mm
Ripple Current @+105°C, 100KHz	115mA Max.
Lifetime @105°C	2000 Hours
Operating Temp. Range	-55°C ~+105°C
Dissipation Factor @+20°C, 120Hz Tanδ Max.	0.22 Tanδ Max.
Leakage Current	16 (μA)max
Impedance @20℃,100KHz	1.1ohm Max.
Mounting Type	Surface Mount, 2 pads
RoHS Status	RoHS III Compliant & Halogen Free
Moisture Sensitivity Level (MSL)	1 (Unlimited)
REACH Status	REACH Unaffected
HTSUS	8532.22.0020
ECCN	EAR99
Standard Package (MPQ)	1000pcs/Reel, Quantity entered must be multiple of 1000
NCNR	Non-Cancelable/Non-Returnable
