SMD Tantalum Capacitors CA45 Series, Case A, EIA code 3216-18, Rated voltage 10 Vdc, Capacitance 2.2μF, Tolerance ±10%, ESR 3.0Ω Max, Operating Temp. Range -55°C ~+125°C.
SMD Tantalum Capacitors CA45 Series, Case A, EIA code 3216-18, Rated voltage 10 Vdc, Capacitance 2.2μF, Tolerance ±10%, ESR 3.0Ω Max, Operating Temp. Range -55°C ~+125°C.
• RoHS III Compliant
• Wide Operating Temperature Range -55~+125℃
• Small volume, High Stability
• Good Frequency Characteristic
APPLICATION
• For Surface Mount Consumer Electronic Equipment
• Color TV sets, PC, Mobile Telephone sets Pickup camera Radar etc.
| Series | CA45 Series Case A |
|---|---|
| Capacitance | 2.2µF |
| Capacitance Tolerance | ±10% |
| Rated Voltage | 10V |
| Case Size | L3.30*W1.70*H1.80mm |
| Dissipation Factor | 6.0% Tanδ Max. |
| ESR | 3.0ohm Max. |
| Operating Temp. Range | -55°C ~+125°C |
| Mounting Type | Surface Mount, 2 pads |
| RoHS Status | RoHS III Compliant & Halogen Free |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| REACH Status | REACH Unaffected |
| HTSUS | 8532.22.0020 |
| ECCN | EAR99 |
| Standard Package (MPQ) | 2000pcs/Reel, Quantity entered must be multiple of 2000 |
| NCNR | Non-Cancelable/Non-Returnable |
